IQ Plus® 2100 Digital Bench Scale
IQ Plus® 2100 Digital Bench Scale 1
IQ Plus® 2100 Digital Bench Scale 3
IQ Plus® 2100 Digital Bench Scale
IQ Plus® 2100 Digital Bench Scale 1
IQ Plus® 2100 Digital Bench Scale 3

IQ Plus® 2100 Digital Bench Scale

$1,815.70 – $1,936.30

  • NEMA Type 4X/IP66
  • 304 stainless steel construction
  • Large, bold 0.8 in LED display
  • Status annunciators: lb, kg, oz, g, negative, motion, center of zero
  • One full-duplex RS-232 port
  • Two digital inputs for remote zero, print and units
  • 12 in column, attachment bracket or tilt stand for table, wall or under counter mounting
  • Aluminum, single-point load cell
  • Overload and upload stops on scale base
  • Stainless steel, non-tactile feel, piezo zero and units buttons
  • Unit of measure: kg, gm, lb, oz, lb/oz (lb/oz is not Legal for Trade)
  • PreVent™ breather vent
  • Factory calibrated

Unmatched Features and Value

The IQ plus® 2100 digital bench scale is ideal for use in general purpose weighing, portioning, and a variety of food processing applications. Stainless steel buttons repel messy ingredient spills and damage by knife point, while the NEMA Type 4X stainless steel indicator enclosure stands up to frequent washdowns. Standard overload stops protect the base during heavy use. All operations are controlled through two buttons—zero and units. Push-button zero and a full range of units, including lb/oz, offer the flexibility needed for a wide variety of applications.

SKU: N/A Category: Tag:
Guaranteed Safe Checkout

IQ plus 2100 Digital Bench Scale Specifications

Power-AC:
Line Voltages
115 or 230 VAC

Frequency:
50 or 60 Hz

Power Consumption:
70 mA at 115 VAC (8 W)
35 mA at 230 VAC (8 W)

Display Resolution:
10,000 graduations maximum

Digital Inputs:
Two inputs, TTL or switch closure, active-low

Scale Frame:
AISI304L, straight line finish, Ra=45 +/- 10

 Scale Cover:
AISI304L, straight line finish, Ra=45 +/- 10

Serial Communications:
Full-duplex RS-232; 9600, 4800, 2400, 1200 bps; seven or eight data bits; even, odd or no parity

Display:
Six-digit light-emitting diode (LED) display
Seven-segment, 0.8 in (20 mm) digits

LED Annunciators:
Negative value, center of zero, motion, kg, g, lb, oz

Keypad:
Two stainless steel piezo switches

 Operating Temperature:
14 °F to 104 °F (-10 °C to 40 °C)

Rating/Material:
NEMA Type 4X/IP66, stainless steel

Load Cell:
Aluminum, environmentally sealed

Warranty:
Two-year limited

Approvals:
Indicator:
NTEP CC 00-045 Class III/IIIL 10,000 d
Measurement Canada AM-5374;
cULus listed
Base:
NTEP CC 95-072, Class III 5,000 d
Model

CKWGHR,IQ+2100 10×10- 5lb w/ Tilt Stand SST 115vac, CKWGHR,IQ+2100 10×10- 10lb w/ Tilt Stand SST 115vac, CKWGHR,IQ+2100 10×10- 25lb w/ Tilt Stand SST 115vac, CKWGHR,IQ+2100 12×12- 50lb w/ Tilt Stand SST 115vac, CKWGHR,IQ+2100 12×12- 100lb w/ Tilt Stand SST 115vac, CKWGHR,IQ+2100 10×10- 5lb w/ Bench Scale Attachment Bracket SST 115vac, CKWGHR,IQ+2100 10×10- 10lb w/ Bench Scale Attachment Bracket SST 115vac, CKWGHR,IQ+2100 10×10- 25lb w/ Bench Scale Attachment Bracket SST 115vac, CKWGHR,IQ+2100 12×12- 50lb w/ Bench Scale Attachment Bracket SST 115vac, CKWGHR,IQ+2100 12×12- 100lb w/ Bench Scale Attachment Bracket SST 115vac, CKWGHR,IQ+2100 10×10- 5lb w/ 12 Inch Column SST 115vac, CKWGHR,IQ+2100 10×10- 10lb w/ 12 Inch Column SST 115vac, CKWGHR,IQ+2100 10×10- 25lb w/ 12 Inch Column SST 115vac, CKWGHR,IQ+2100 12×12- 50lb w/ 12 Inch Column SST 115vac, CKWGHR,IQ+2100 12×12- 100lb w/ 12 Inch Column SST 115vac
